DURABILITY
-Built to Last
-4 x 8” HSS tubular steel (1/4” wall) trailer frame construction.
-8” x 8” HSS tubular steel booms. Wall thickness is ¼” for models up to 50’ and 3/8” wall thickness for models above 50’.
-Steel hydraulic lines on booms.
-Powder coat paint

TINE WEAR LIFE
-Parallel linkage and balanced downforce result in uniformtine wear from front to back of the harrow section.
-MH-7200 uses MAX LIFEBTT harrow tines that last 6X longer than regular tines.
-TheMAX LIFEprocess infuses tungsten carbide onto the harrow tine creating the toughest and most economical option available. Field tests have proven thatMAX LIFEtines outlast regular tines by a minimum of 6X.
-Our field evaluations indicate that the MAX LIFE system is less prone to crop residue ‘hooking’ observed with carbide plated tines .
-MAX LIFE vs. regular tine after 10,000 acres of wear

PRODUCTIVITY

-Hydraulic Tine Angle & Down Pressure
-Adjust tine angle from 40 –85°using the hydraulic remote in your tractor cab.
-Increase tine angle for more aggressive harrowing in dry conditions.
-Decrease tine angle for wet conditions to reduce straw held in harrows and spread straw uniformly.
-Increase tine angle for more aggressive harrowing in dry conditions.
-Increasing down force onto the harrows is simple –increase tine angle.

AUTOFOLD
-Rear pivoting wheels make folding and unfolding the harrow easy.

SOLID DRAFT ARM SYSTEM

-Draft arms lock into place using a unique locking mechanism.
-Draft arms allow the operator the ability to lift the harrows and back up the machine to avoid running into obstructions.
-No more ‘cable related drama’.

EASY TIME REPLACEMENT

-Servicing tines is as easy as removing 1 bolt and pulling the harrow bar from the formed steel receiver.
